DJI Dock 2: Compact automated drone dock for remote, repeatable operations

DJI Dock 2 is an automated dock system designed for secure, repeatable remote drone operations with DJI Matrice 3D and Matrice 3TD aircraft. The dock is built to reduce deployment overhead while improving operational consistency through integrated environmental monitoring, internal and external security cameras, and cloud-based operation through DJI FlightHub 2. Dock 2 is rated IP55 and supports unattended outdoor use within published environmental limits. It also includes an onboard backup battery for continued operation during power interruptions, helping maintain mission continuity and controlled recoveries.

Dock 2 features and benefits

• Lightweight redesign: 75% smaller and 68% lighter than predecessor.
• IP55 protection: Dust and water resistance for outdoor automated operations.
• Dual RTK antennas: Supports accurate RTH without RTK convergence delay.
• Rapid launch sequence: Propeller inspection and takeoff in 45 seconds.
• Fast recharge cycle: Charges 20% to 90% in 32 minutes.
• Dual fisheye cameras: Internal and external monitoring with 151° FOV.
• Environmental monitoring sensors: Tracks wind, rainfall, and key cabin conditions.
• Backup battery: Supports over five hours of independent dock operation.

IP55 enclosure and environmental monitoring for dependable outdoor uptime

DJI Dock 2 is designed for extended outdoor deployment with an IP55 ingress protection rating and an integrated environmental monitoring system. Supported sensors include wind speed, rainfall, ambient temperature, water immersion detection, and in-cabin temperature and humidity monitoring. These inputs help operators understand site conditions remotely and support more reliable automated operations. For resilience during unexpected outages, Dock 2 includes a built-in backup battery capable of operating independently for over five hours under specified conditions, providing time for aircraft recovery and controlled landing during disruptions.

High-tempo operations with rapid takeoff, fast charging, and remote oversight

Dock 2 is engineered to keep automated missions moving with minimal on-site intervention. DJI specifies rapid takeoff in as little as 45 seconds, supporting quick entry into operational status for time-sensitive tasks. Dock charging performance is specified as 32 minutes from 20% to 90% with the aircraft powered off at 77°F (25°C), supporting consecutive sorties. Remote oversight is supported through internal and external security cameras and cloud-based tools that enable model-based planning, route editing, FlyTo tasking, and emergency notifications through DJI FlightHub 2.

Aircraft and software compatibility

• Supported aircraft: DJI Matrice 3D and DJI Matrice 3TD only.
• Deployment software: DJI Pilot 2 via DJI RC Pro Enterprise.
• Cloud platform: DJI FlightHub 2 supported by default.
• Third-party cloud support: Available through DJI Cloud API access.
• Network access: 10/100/1000 Mbps adaptive Ethernet port supported.
• Video transmission: O3 Enterprise supported for dock operations.
• Optional connectivity: Supports DJI Cellular Dongle 2 for 4G linking.

Operational scenarios for automated inspection, security, and remote monitoring

• Perimeter security monitoring: Schedule repeatable patrol routes with remote oversight.
• Emergency response: Launch quickly for time-sensitive situational awareness missions.
• Infrastructure inspection: Automate routine checks with consistent flight repeatability.
• Construction site documentation: Capture regular progress imagery with minimized staffing.
• Environmental monitoring: Use onboard sensors to assess conditions before flights.
• Remote area operations: Reduce site visits using cloud-based mission management.
• After-hours site coverage: Maintain automated availability outside normal work shifts.
• Incident follow-up: Use recorded events and notifications for troubleshooting.

Built for enterprise deployment

DJI Dock 2 is designed for professional operations that demand predictable uptime and scalable remote management. A published six-month maintenance interval helps standardize service planning across deployed sites. Integrated lightning protection specifications are provided for both AC power and Ethernet ports, supporting more resilient installations. With DJI FlightHub 2 as the default cloud platform and access via DJI Cloud API for third-party systems, Dock 2 supports structured integration into enterprise monitoring and response workflows. This combination improves repeatability while reducing operational burden.

DJI Dock 2 delivers a compact, hardened platform for automated remote drone operations with consistent deployment outcomes. It is built to support repeatable missions, reduced on-site staffing, and controlled workflows across distributed locations.

DSLRPros supports end-to-end Dock deployments, from site planning to operational onboarding and ongoing support. Available now from DSLRPros. Purchase today to standardize automated operations with DJI Dock 2.
